MidNite Solar

MidNite MNEPV-600RT 20A 600VDC DIN Rail Mount Breaker

MidNite MNEPV-600RT 20A 600VDC DIN Rail Mount Breaker

Regular price $199.00 CAD
Regular price Sale price $199.00 CAD
Sale Call for availability!
Shipping calculated at checkout.
Quantity

The MidNite MNEPV-600RT is a 20 Amp, 600 VDC DIN rail mount breaker designed for safe and reliable overcurrent protection in solar and DC power systems. Built for performance, it can be used at 100% rated current when installed in a MidNite Solar enclosure, ensuring maximum efficiency without compromise.

Engineered to break its full rated load at the rated voltage repeatedly with no damage, this breaker delivers long-lasting durability and dependable safety in demanding environments.

Specifications:

  • Current Rating: 20A
  • DC Voltage Rating: 600VDC
  • Poles: 4 (polarized)
  • Width: 2 inches (52mm)
  • Wire Size Range: 14–6 AWG
  • Torque Value: 20 in-lbs (2.3 Nm)
  • Environmental Rating: Type 1 (indoor use)
  • Certifications: Listed for US & Canada when used in MidNite Solar enclosures
  • Warranty: 5 years

Key Benefits:
✔ Reliable protection with no performance loss
✔ Suitable for solar and other DC applications
✔ Designed for durability in high-voltage systems
